Plotly Scatter Plots

Plotly Scatter Plots

Welcome to another exciting dive into the world of Python visualization! Today, we’re going to explore one of the most versatile and powerful chart types available in Plotly: the scatter plot. If you’ve ever wanted to visualize relationships, clusters, trends, or distributions in your data, scatter plots are often the perfect tool. And with Plotly, creating interactive, publication-quality scatter plots has never been easier.

Let’s get started by making sure you have the right tools installed. If you haven’t already, install Plotly using pip:

pip install plotly

Now, let’s jump into your first scatter plot. The simplest way to create a scatter plot in Plotly is by using the plotly.express module, which is designed for quick and easy plotting. Here's a minimal example:

import plotly.express as px

# Sample data
x = [1, 2, 3, 4, 5]
y = [2, 4, 6, 8, 10]

fig = px.scatter(x=x, y=y, title="My First Scatter Plot")
fig.show()

When you run this, you'll see an interactive plot where you can zoom, pan, and hover over points to see their values. That’s the magic of Plotly—your visualizations come to life with interactivity right out of the box.

Of course, you’ll usually be working with more structured data, like a pandas DataFrame. Let’s create a DataFrame and use it to make a scatter plot:

import pandas as pd

df = pd.DataFrame({
    'height': [150, 160, 170, 180, 190],
    'weight': [50, 60, 70, 80, 90]
})

fig = px.scatter(df, x='height', y='weight', title="Height vs Weight")
fig.show()

See how easy that was? By passing the DataFrame and specifying the column names for x and y, Plotly does the rest.

Customizing Your Scatter Plot

One of the strengths of Plotly is its extensive customization options. Let’s say you want to change the color and size of the points, or maybe add labels. Here’s how you can do it:

fig = px.scatter(
    df,
    x='height',
    y='weight',
    title="Height vs Weight",
    color_discrete_sequence=['red'],
    size_max=15
)
fig.show()

But what if you have a third variable you want to represent? For example, imagine you have a "gender" column and you want to color the points based on that. You can do it easily:

df['gender'] = ['F', 'F', 'M', 'M', 'M']

fig = px.scatter(
    df,
    x='height',
    y='weight',
    color='gender',
    title="Height vs Weight by Gender"
)
fig.show()

Now each gender has a different color, making it easy to distinguish between groups.

You can also use the size of the points to represent a fourth variable. Let’s add an "age" column and map it to the size:

df['age'] = [25, 30, 35, 40, 45]

fig = px.scatter(
    df,
    x='height',
    y='weight',
    color='gender',
    size='age',
    title="Height vs Weight by Gender and Age"
)
fig.show()

Now you have four dimensions in one plot: height, weight, gender, and age. How cool is that?

Let’s take a look at a sample dataset to see these features in a more realistic context.

Height (cm) Weight (kg) Gender Age
150 50 F 25
160 60 F 30
170 70 M 35
180 80 M 40
190 90 M 45

This table shows the data we just used. With just a few lines of code, you turned this table into an insightful, interactive visualization.

Here are a few more ways you can enhance your scatter plots:

  • Add trendlines
  • Adjust opacity for overplotted points
  • Change the marker symbol for different categories
  • Set custom hover text

Let me show you an example with a trendline:

fig = px.scatter(
    df,
    x='height',
    y='weight',
    trendline="ols",  # ols for ordinary least squares regression
    title="Height vs Weight with Trendline"
)
fig.show()

This adds a linear regression line, which can help in understanding the relationship between the two variables.

Using Plotly Graph Objects for More Control

While plotly.express is great for quick plotting, sometimes you need more control. That’s where plotly.graph_objects comes in. It’s a bit more verbose but offers fine-grained customization. Here’s how you create the same scatter plot with graph_objects:

import plotly.graph_objects as go

fig = go.Figure()

fig.add_trace(go.Scatter(
    x=df['height'],
    y=df['weight'],
    mode='markers',
    marker=dict(size=10, color='blue')
))

fig.update_layout(title="Height vs Weight with Graph Objects")
fig.show()

With graph_objects, you can build your plot step by step, adding multiple traces (layers) and customizing each element individually.

For instance, if you want to add both points and lines, you can change the mode:

fig.add_trace(go.Scatter(
    x=df['height'],
    y=df['weight'],
    mode='markers+lines',  # markers and lines
    name='Data Series'
))

This is just the tip of the iceberg. You can add annotations, shapes, and even subplots using graph_objects.

Advanced Features

Now let’s explore some advanced features that make Plotly scatter plots stand out.

First, let’s talk about hover information. By default, when you hover over a point, you see the x and y values. But you can customize this to show additional data:

fig = px.scatter(
    df,
    x='height',
    y='weight',
    hover_data=['age', 'gender'],
    title="Custom Hover Info"
)
fig.show()

Now when you hover, you’ll see the age and gender along with height and weight.

Another powerful feature is animation. You can animate your scatter plot to show changes over time or across categories. For example, if you had data across multiple years, you could animate the points to show how they move:

# Assuming we have a 'year' column
df['year'] = [2010, 2010, 2011, 2011, 2012]

fig = px.scatter(
    df,
    x='height',
    y='weight',
    animation_frame='year',
    title="Animated Scatter by Year"
)
fig.show()

This creates a play button that lets you step through each year, watching the points change position.

You can also create 3D scatter plots for an even richer view of your data:

fig = px.scatter_3d(
    df,
    x='height',
    y='weight',
    z='age',
    color='gender',
    title="3D Scatter Plot"
)
fig.show()

Now you can explore your data in three dimensions, rotating and zooming to get the best view.

Let’s not forget about styling. You can customize every aspect of your plot’s appearance, from the background color to the font:

fig.update_layout(
    plot_bgcolor='lavender',
    paper_bgcolor='lightgray',
    font=dict(size=14, color='darkblue')
)

These are just a few examples—the possibilities are nearly endless.

Best Practices for Effective Scatter Plots

Creating a scatter plot is easy, but creating an effective one requires some thought. Here are a few tips:

  • Choose appropriate axis scales: Sometimes a log scale can make patterns clearer.
  • Avoid overplotting: If you have too many points, consider using transparency or sampling.
  • Use color wisely: Choose a color palette that is accessible and meaningful.
  • Label everything: Always include axis labels, a title, and a legend if needed.

For example, to set a log scale on the x-axis:

fig.update_xaxes(type='log')

And to adjust opacity for overplotting:

fig = px.scatter(
    df,
    x='height',
    y='weight',
    opacity=0.6  # 60% opacity
)

Integrating with Dash for Web Applications

If you’re building a web application, you can integrate Plotly scatter plots with Dash, Plotly’s framework for building analytical apps. Here’s a minimal example:

from dash import Dash, dcc, html
import plotly.express as px

app = Dash(__name__)

fig = px.scatter(df, x='height', y='weight')

app.layout = html.Div([
    dcc.Graph(figure=fig)
])

if __name__ == '__main__':
    app.run_server(debug=True)

This creates a local web server with your scatter plot embedded. You can add callbacks, inputs, and other interactive elements to make it dynamic.

Exporting Your Plots

Once you’ve created your masterpiece, you might want to save it. Plotly supports multiple formats:

fig.write_image("scatter_plot.png")  # PNG, JPEG, SVG, PDF, etc.
fig.write_html("scatter_plot.html")  # Interactive HTML

This makes it easy to share your plots in reports, presentations, or on the web.

Common Pitfalls and How to Avoid Them

Even with a powerful library like Plotly, things can go wrong. Here are a few common issues and how to fix them:

  • Missing data: If your data has NaNs, Plotly might not plot those points. Consider cleaning your data first.
  • Too many points: Plotting millions of points can slow down your browser. Use sampling or aggregation.
  • Incorrect data types: Make sure your columns are numeric for axis mappings.

For example, to handle missing data:

df_clean = df.dropna()
fig = px.scatter(df_clean, x='height', y='weight')

And to sample large data:

df_sample = df.sample(n=1000)  # random sample of 1000 points
fig = px.scatter(df_sample, x='height', y='weight')

Real-World Example

Let’s wrap up with a more realistic example using a built-in dataset. Plotly comes with several sample datasets. Here’s one using the iris dataset:

df_iris = px.data.iris()
fig = px.scatter(
    df_iris,
    x='sepal_width',
    y='sepal_length',
    color='species',
    title="Iris Dataset: Sepal Width vs Length"
)
fig.show()

This plots the famous iris dataset, coloring points by species. You can immediately see the clusters corresponding to different types of iris flowers.

I hope this guide has shown you just how powerful and flexible Plotly scatter plots can be. Whether you’re exploring data, presenting results, or building an app, scatter plots are a fundamental tool in your visualization toolkit. With Plotly, you can create stunning, interactive plots with minimal code, and customize them to fit your exact needs.

Happy plotting
